SUG220-D6

Unmanaged Industrial Switch SUG220-D6

€0,00

  • 2 * 10/100/1000Base-TX (RJ45) ports
  • 2 * 100/1000Base-X (SFP) ports
  • Without PoE
  • 12-58VDC Redundant Power Inputs

Out of stock

Category:
Ports
RJ45 ports and speed 2 * 10/100/1000Base-TX
Fiber ports and speed 2 * 100/1000Base-X SFP
Ethernet
Processing type Store and Forward
Max Packet Length 9KB
Packet Buffer 1Mb
MAC Address Table 2K
PoE Not supported
Standards IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3ab
Environmental
Operating Temperature -40oC ~ +75oC
Storage Temperature -40oC ~ +85oC
Relative Humidity 0 ~ 90% non-condensing
MTBF 480.000h
Electrical and Physical
Redundant Power Inputs 12-58VDC
Max Power consumption 5W
Cooling Natural cooling, no fan design
Dimensions (H * D * W) 85 * 85 * 30mm
Weight 300g
Mounting Din-rail / Wallmount
Certification
Standards
Surge protection for power ports: 4KV/2KV (EN 61000-4-5)
Surge protection for Ethernet ports: 4KV/2KV (EN 61000-4-5)
Vibration: IEC 60068-2-6:2007
Shock: IEC 60068-2-27:2008
Free fall: IEC 60068-2-32:1975
CE 2014/30/EU EMC, EN 55032:2015/A11:2020, EN 55035:2017/A11:2020
EN 61000-3-2:2019/A2:2024, EN 61000-3-3:2013/A2:2021/AC:2022-01
EN 61000-4-2:2009, EN 61000-4-3:2020, EN 61000-4-4:2012
EN 61000-4-5:2014/A1:2017, EN 61000-4-6:2023
CE 2014/35/EU LVD, EN IEC 62368-1:2024
FCC Part 15, Subpart B:2016, ANSI C63.4:2014
RoHS 2011/65/EU, (EU) 2015/863, (EU) 2017/2102
SUG220-D6 series Unmanaged Switches datasheet (0.3MB)

Unmanaged Industrial Ethernet Switch Quick Installation Guide (0.2MB)


Description

The SUG220-D6 Industrial grade Unmanaged Ethernet Switch is designed to switch and transmit 10/100/1000Mbps Ethernet over optical fiber through user selectable SFP module options. The SFP port auto detects 100Base-FX and 1000Base-X  SFP modules, which makes this unit universal for 100Mbps and 1Gbps fiber networks. Housed in rugged metal Din-rail or wall-mountable enclosure, no fan design with redundant power inputs and extreme temperatures operation, makes those switches a perfect choice for critical environments, such as security, transportation, airports, industrial networking or even military applications.





Additional information

# of RJ45 ports

2
# of SFP ports

2
PoE

None
Port Speed

100Mbps, 1Gbps
Management

Unmanaged
Operating Temperature

From -40C to +75C
